Specification

Range:

Sphere Lens 0 to ±35D (Increments 0.01D/0.06D/0.12D/0.25D)

Range: Increments

<0D, ≥-5D >0D, ≤+5D                             ±0.06

<-5D,≥-10D >+5D,≤+10D                            ±0.09

<-10D,≥-15D >+10D,≤+15D                           ±0.12

<-15D,≥-20D >+15D,≤+20D                           ±0.18

<-20D,≥-35D >+20D,≤+35D                           ±0.25

Cylinder Lens: 0 to±10D (Increments 0.01D/0.06D/0.12D/0.25D)

Axis: 0°to 180 (Increments 1°)

ADD: 0 to 10D (Increments 0.01D/0.06D/0.12D/0.25D)

Prism: 0 to 15A (0.01△)

Prism Range Increments

>0△, ≤5△                0.1△

>5A, ≤15△                0.2△

Cylinder Mode : +，+/-，-

Prim Mode: cartesian coordinates H: l,o .v: u,D P-B;polar coordinates

mm: X and Y in mm

Increments: 0.01D/0.06D/0.12D/0.25D

Measure single vision lens, bifocal lens, trifocal lens and progressive lens, etc.

UV/Blue Light Transmissivity Detection

CL Lens Accessible

Reflect Ratio: >10% Reflect Ratio while Diopter over +/-10D > 20%

Contact lens: 0 to ±25D, BC 6.00 to 9.00

Monitor: 7.0 Inch HD Touch Screen

Menu: humanized Design and Easy Operation

Lens Diameter Capacity: 20mm-100mm

Voltage: AC 100 (±10% ) -240 ( ±10%)v 50/60Hz 40VA

Power: 40w

Weight: 6.8kgs

Machine Size:550mm*350mm*350mm(L*W*H)

Storage Condition

a.Temperature:5-40℃ (In use）-20-60°c( Storage/Transportation)

b. Humidity: 30-85% 10-95% (Storage/Transportation)

c. Air Pressure: 700-1060hpa

d. Altitude: up to 2000m

e. Others: No Harmful Dust or Smog
