Feature

◆ The product is designed with compact structure, complete functions and is able to use in small space.

◆ The magnification range is continuous variable from 4× to 24×, horizontal movement and fine focusing can be adjusted by foot control.

◆ Schott optic glasses are used to provide strong resolving power of optical system, clear image quality and uniform field of view.

◆ Applied to microsurgery and meticulous examinations of ophthalmology, ENT, etc.

◆ Optional 180° eyepiece tube.

Specifications

Eyepiece Magnification	12.5×, 16×
Diopter Adjustment	±6D
View Angle of Eyepiece	30°~90°，optional 180° eyepiece tube
Magnification for Main Microscope(Diameter of Field)	4×~24× (φ41.5mm~φ7.5mm)
Focal Length of Objective Lens	f=200 mm, optional f=175/250/300 mm
Pupilary Adjustment	50 mm ～ 75 mm
Maximum Resolution	119 LP/mm
Working Distance	190 mm
Light Source	15V/150W, medical cold reflection halogen lamp
Illumination Type	6°+0° coaxial illumination
Coaxial Illuminance	≥40,000 Lx
Filters	Orange fliter( optional cobalt blue filter)
Reaching Radius of Arm	1020 mm
Adjustable Vertical Range	±250 mm
Fine Focusing Speed and Range	≤2 mm/s，30 mm
Speed for X/Y and Range	≤2 mm/s，50 mm×50 mm
Input Voltage	AC 220V/110V±10%, 50Hz/60Hz
Power Consumption	220 VA
Fuse	AC 250V   T4.0A, AC 125V  T8.0A
Electrical Safety Standard	IEC 60601-1, Class I
Packing Volume	0.418 m3，2 cartons
Total Weight	87 kg
