RM-800 Contrast Sensitivity function tester, the third generation product of contrast sensitivity series in Wenzhou Raymond Tech. Co.Ltd, has a series of authentic data ,which is widely used in clinical medicine and scientific research. As a detecting vector, RM800’s data is not only published in domestic journal articles, but also published in international core journal paper of SCI series.

Main functions

1：Contrast sensitivity function test（CS）.

2：Dark adaptation test.

3：Glare contrast sensitivity function test（GS).

4：CS range diagram.

5：Long/short distance contrast sensitivity test.

6：Light/dark environment sensitivity test.

Main clinical applications:

1：Test human eyes’ CS function in different luminance and contrast;Apply to excimer operation and IOL.

2：Necessary in Dark adaptation test, eye test of sailors and drivers, and physical examination.

3：Sensitive to glaucoma, macula disease, diabetic retinopathy, optic nerve diseases and amblyopia.
4：Light/dark environment and long/short distance contrast sensitivity test.

Specification

1：Spatial frequency range: 1.8;3;6;12;18;24（Unit：CPD）

2： CSrange:1%-100% 12gears

3：Simulation test distance: Distant(Standard) 5m    Close  400mm

4：Simulation environment test: Light environment(Standard) Dark environment

5：Glare: Equipped:

6：Test-object form: Sinusoidal grating test-object

7：Dark adaption test: Standard 5OS, 6 gears can be chosen

8：Power supply:

Input voltage                          220V

Input frequency                        50/60Hz

Input powe                             60VA

9: Size                                    520x 280x 420 mm

10: Weight                                 15KG
