  • LY-9G PD&PH Meter

Features:
The PD&PH Meter is a digital precision optical instrument used to measure PD, PH and VD in the process of optometry for fitting spectacles.
1. t employs precise optical structure; the line of light is very clear and precise measurement. The measurement results are displayed digitally, and the left eye and right eye measuring values are displayed separately.
2. Simple and rapid measuring operation, and free operation of the direct PD adjustment lever are possible. Combining with the adjustable viewing distance selecting lever for measuring all kind of the viewing distances, the PD measurement is simple and precise.
3. When the measuring operation is finished, the auto power off and memory function, enable to save the power and not to lose the data.
4. It can also be used in monocular the left eye and right eye separately.



echnical Specifications:

Technical Data

LY-9G

Effective range of measurement

binocular pupillary

Distance

46-82mm

Left or right pupillary distance

23-41mm

Indication error

<0.5mm

Distance of target

30cm~∞

Electric Voltage

DC 3V(2pcs 5# AA battery)

Weight

0.7kg

Volume

28(L)x19(w)x10(H)cm
